The LP6297B is a 8-CH high voltage level shifter for TV and monitor LCD applications.It converts logic level signals from Timing Controller(T-CON)to high level signals used by the LCD panel.

The outputs are switching from VGL to VGH,with capacitive loads up to 5nF.

Other features include short circuit protection,thermal shutdown protection and under-voltage lockout(UVLO).The LP6297B is available in a space saving TQFN-32(0.4mm pitch)package.

1,Features
•-20V to 40V High Output Level
•Support Two Kinds of TCON Input Signals
-TCON Mode 0
-TCON Mode 1
•High Output Slew Rate to Drive Up to 5nF Load
•Over Current Protection
•Over Temperature Protection
•Available in TQFN-28(4×4mm)
•Available in TQFN-32(4×4mm)
•RoHS Compliant and Halogen Free.
•Pb-Free Package.

2,Applications
•TFT for NB Using GOP/IPS Technology
•TFT for Monitors Using GOP/IPS Technology
•TFT for TV Using GOP/IPS Technology.
